Gaas Fet Transistor

Designed for use in driver stages of moderate power RF amplifiers to 2 GHz. Typical applications are cellular radios and personal communication transmitters such as AMPS, ETACS, NMT, GSM, PCN, JDC and DECT. Performance Specifications at 900 MHz, 5.8 V: Output Power = 21 dBm Power Gain 14 dB Min Drain Efficiency = 55% Min Plastic Surface Mount Package Order MRF9811T1 for Tape and Reel Packaging. T1 Suffix = 3,000 Units per 8 mm, 7 inch Reel.

Rating Drain­Source Voltage Gate­Source Voltage Drain Current Continuous Total Device Dissipation = 50°C Derate above 50°C Storage Temperature Range Operating Junction Temperature Symbol VDSS VGS ID PD Tstg TJ Value to +150 Unit Vdc Adc W mW/°C °C

Gate­Drain Breakdown Voltage (IGD = 0.25 mA, Source Open) Zero Gate Voltage Drain Current (VDS = 1.5 Vdc, VGS = 0) Gate­Source Leakage Current (VGS = ­5.0 Vdc, Drain Open) V(BR)GDO IDSS IGSO Vdc Adc µAdc

NOTE ­ CAUTION ­ MOS devices are susceptible to damage from electrostatic charge. Reasonable precautions in handling and packaging MOS devices should be observed.

Gate Threshold Voltage (VDS = 5.8 Vdc, 0.25 A) Forward Transconductance (VDS = 5.8 Vdc, = 30 mA) VGS(th) gfs Vdc mmhos

Common Source Output Power (VDS 5.8 V, IDQ = 30 mA, Pin = 7 dBm, = 900 MHz) Drain Efficiency (VDS 5.8 V, IDQ = 30 mA, Pin = 7 dBm, = 900 MHz) Gps dB %
